Material:
Steel
|
|
Lifting capacity:
40 ton / 20 ton
|
|
Lifting height min.:
150 mm
|
|
Lifting height max.:
409 mm
|
|
Platform dimensions:
ø70 mm
|
|
Handle length:
1300 mm
|
|
Wheel material:
Rubber/polypropylene
|
|
Wheel diameter:
ø165 mm
|
|
Working air pressure:
9 - 12 bar
|
|
Air consumption:
300 L/min
|
|
Air connection:
1/4" BSP
|
|
Oil capacity:
1 L
|
|
Oil type:
OHCH15V
|
