Lifting capacity:
2000 kg
|
|
Lifting height min.:
84 mm
|
|
Lifting height max.:
200 mm
|
|
Battery type:
lithium-ion
|
|
Battery voltage:
48V/15Ah
|
|
Power supply:
230V
|
|
Drive motor power:
1 kW
|
|
Lift motor power:
0.8 kW
|
|
Lifting speed loaded:
18 mm/sec
|
|
Lifting speed unloaded:
23 mm/sec
|
|
Lowering speed loaded:
56 mm/sec
|
|
Lowering speed unloaded:
46 mm/sec
|
|
Driving speed loaded max.:
4 km/h
|
|
Driving speed no-load max.:
4.5 km/h
|
|
Gradeability max. loaded / unloaded:
6% / 20%
|
|
Turning radius:
1353mm
|
|
Fork size (length x width x height):
1150 x 160 x58 mm
|
|
Fork overall width:
550 mm
|
|
Wheel material:
Polyurethane
|
|
Steering wheel diameter:
140 mm
|
|
Load wheel diameter:
80 mm
|
|
Brake type:
Electromagnetic
|
|
Battery life:
Approx. 4.5 hours (room temperature); 30–45 min during continuous use in cold environments. When alternating between cold and room temperature, the normal runtime is maintained.
|
